Water Cooled Chillers

Water Cooled Chillers

200000.00 INR/Piece
Get a Price/Quote

Product Details:

  • Motor Three Phase Induction Motor
  • Refrigerating Capacity 40 TR (140.8 kW)
  • Application Industrial Process Cooling, HVAC, Plastic Processing Industries, Chemical, and Pharmaceutical Industries
  • Air Flow (Water cooled units do not utilize air flow for cooling condenser)
  • Material Mild Steel Body with Powder Coated Finish
  • Condition New
  • Type Water Cooled Chiller
  • Click to View more
Request to Call Back Send Inquiry
X

Water Cooled Chillers Price And Quantity

  • 1 Piece
  • 200000.00 INR/Piece
  • 2
  • AAA
  • Yes
  • Built-in WiFi, Screen Mirroring
  • 178
  • 60 Hz
  • Android

Water Cooled Chillers Product Specifications

  • Water Cooled Chiller
  • 3 Phase, 50 Hz
  • 3 HP
  • 40 TR (140.8 kW)
  • Three Phase Induction Motor
  • 415 V AC
  • 20 m/hr
  • New
  • Low Noise (<72 dB(A))
  • Industrial Process Cooling, HVAC, Plastic Processing Industries, Chemical, and Pharmaceutical Industries
  • Water Cooled
  • Copper Tubes with Aluminum Fins
  • (Water cooled units do not utilize air flow for cooling condenser)
  • Hermetically Sealed / Semi-Hermetic Reciprocating Compressor
  • Brass
  • 1900 mm x 1100 mm x 1600 mm
  • Mild Steel Body with Powder Coated Finish
  • 2
  • AAA
  • Yes
  • Built-in WiFi, Screen Mirroring
  • 178
  • 60 Hz
  • Android

Water Cooled Chillers Trade Information

  • Cash in Advance (CID), Cheque, Cash Advance (CA)
  • 10 Piece Per Week
  • 1 Week
  • Wooden Packing, As per product
  • Australia, Central America, North America, South America, Western Europe, Middle East, Asia, Eastern Europe, Africa
  • All India
  • ISO 9001: 2015

Product Description

We are pleased to inform that we offer robust Water Cooled Scroll Chiller (SINGLE COMPRESSOR) that are made using scroll compressors that we purchase from renowned agencies like danfoss-maneurop and Copeland. Our water cooled chillers are fully microprocessor based and suitable for process cooling applications varying from (+) 20degree c up to (-) 15degreec. The temperatures can go even lower till to (-) 50degree c for which you can refer brine chillers. Water cool chilling machine come with multiple scroll compressors each having a separate refrigeration circuit. Our chillers are manufactured in compliance to ISO 9001:2008 standards. These Water Cooled Chiller machine are also rated for ambient of up to (+) 480c with water cooling tower temperature that goes up to (+) 37degree c at the inlet of the condenser.

The different operating voltages for these chillers are:
  • 460 volt ac / 50 hz
  • 380 / 400 volt ac / 50 hz
  • 380 volt ac / 60 hz
  • 460 volt ac / 60 hz
Design data:
  • Design condensing temperature (+) 40 degree c
  • Connected power 415v ac +/- 10 percent / 50 Hz / 3 phase + neutral
  • Design evaporating temperature (+) 5 degree c
Features:
  • Innovative attributes
  • Free of CFC refrigerant
  • Very low input KW/TR
  • State-of-the-art construction
  • Developed using advanced technology
  • Liquid injection done to enhance compressor life
  • Heat exchanger design as per TElvlA/ASME/SEC VIII, DM, 2001
  • MCS microprocessor/PLC based/electromechanical

Specifications:

MODEL

CAPACITY

COMPRESSORS

FLOW RATE

DCS WST

TR


CMH

DCS-W-3

3 TR

1

1.8

DCS-W-6

6 TR

1

3.6

DCS-W-8

8 TR

1

4.8

DCS-W-11

11 TR

1

6.6

DCS-W-12

12 TR

1

7.2

DCS-W-15

15 TR

1

9.0

DCS-W-20

20 TR

1

12.0

DCS-W-25

25 TR

1

15.0

DCS-W-30

30 TR

1

18.0

FAQ

1. What is a water-cooled chiller, first off?

Ans - A refrigeration system known as a "water cooled chiller" uses water to cool a process or area. Condenser, compressor, evaporator, and expansion valve are the typical components.

2. What advantages can water cooled chillers offer?

Ans - Efficiency is the fundamental advantage of employing a water-cooled chiller. When compared to air cooling, water cooling is more effective and can be used to cool big areas or operations that call for a lot of cooled air. Additionally, compared to other types of chillers, water-cooled chillers are more dependable, quieter, and require less maintenance.

3. How do chillers with water cooling operate?

Ans - A refrigerant is used by water-cooled chillers to remove heat from a system or area. In the chiller, a number of coils that are cooled by water conduct the refrigerant. After cooling, the refrigerant is recirculated throughout the system or area to continue removing heat.

4. For what kinds of applications is a water-cooled chiller necessary?

Ans - Common uses for water-cooled chillers include cooling huge industrial processes or commercial buildings, which call for a lot of cooled air.

5. How often does a water-cooled chiller need maintenance?

Ans - Any type of chiller, including water cooled chillers, requires routine maintenance. This entails cleaning the condenser coils, monitoring the refrigerant levels, and checking the coolant levels. Additionally, its crucial to look for any leaks or other problems that could reduce the chillers effectiveness.


Efficient Industrial Cooling Solutions

Designed for continuous and reliable operation, our water-cooled chillers cater to various industries, including plastic, pharmaceutical, chemical, and HVAC sectors. Whether you require process cooling or comfort air conditioning, these chillers excel in maintaining outlet temperatures between +5C and +20C.


Robust Construction and Advanced Features

Built with powder-coated mild steel bodies and high-grade copper tube coils, the chillers offer resilience in demanding environments. Integrated digital microprocessor controls and multiple safety devicessuch as compressor overload protection and flow switchesensure safe and efficient performance.


Environmentally Friendly & Energy Efficient

Choose from eco-friendly refrigerants (R22, R407C, R134a) with high energy efficiency. Our chillers provide reliable cooling while minimizing environmental impact, thanks to cutting-edge design and efficient motor-compressor assemblies.

FAQs of Water Cooled Chillers:


Q: How does a water-cooled chiller operate in industrial applications?

A: A water-cooled chiller works by circulating chilled water through a shell and tube heat exchanger, absorbing process or ambient heat, and then dissipating this heat via a water-cooled condenser. This system is ideal for continuous process cooling in industries such as plastics, pharmaceuticals, and chemicals.

Q: What are the advantages of choosing a shell and tube condenser?

A: Shell and tube condensers offer high efficiency, durability, and ease of maintenance. They handle large water flow rates (20 m/hr) efficiently and are well-suited for high-capacity cooling in industrial environments.

Q: When should you use a water-cooled chiller over an air-cooled one?

A: Water-cooled chillers are preferred when high cooling capacities (up to 200 TR) and stable, low noise operation are required. They perform better in facilities with access to a steady water supply and where heat needs to be rejected efficiently within a limited space.

Q: Where can these chillers be installed?

A: These chillers are suitable for installation in industrial plants, pharmaceutical facilities, chemical processing units, and commercial buildings requiring process or comfort cooling. The chillers compact design accommodates various site layouts.

Q: What protections and safety features are included in these chillers?

A: Safety integrations include high/low pressure cutouts, compressor overload protection, phase failure relay, water flow switch, and phase sequence protectionensuring long-term safe operation and equipment longevity.

Q: How are eco-friendly refrigerants like R407C and R134a beneficial?

A: Refrigerants such as R407C and R134a reduce environmental impact by offering lower ozone depletion potential and better energy efficiency, while maintaining effective cooling performance in industrial applications.

Q: What is the process for setting the desired temperature?

A: The microprocessor-based digital controller allows precise adjustment of outlet water temperature (from +5C to +20C). Simply program your required setpoint, and the controller will automatically maintain the desired temperature using thermostatic expansion valves and responsive sensors.
